MultiFlow  Printing out Reports
Event
Data
Meaning
ReConfig detect
Change to configuration detected.
Stopped
Communication with module cancelled.
Error solved
Error status automatically rectified.
External IO module events.
EIO
INx change:y
Status at input x of the IO module changed to status
y.
Information about external sensor module.
SIInfo
Online
External sensor module connected and ready for
operation.
Connect lost
Interrupted CAN communication.
Onl.Reset
Reset detected in online mode.
Unconf. change
Change to non-configured sensor detected.
ReConfig detect
Change to configuration detected.
Stopped
Communication with module cancelled.
Disabled
Sensor module operation cancelled.
Unkn.Sensor x
Sensor event detected for unknown sensor x.
No conf.Change
Short-term sensor change not confirmed.
Unkn.Sensor x
Change to unused sensor x.
Error solved
Error status automatically rectified.
NamurReset NAK
SI Namur status cannot be reset.
SetDate NAK
Date/time cannot be updated.
ScanInterv.NAK
Scan interval configuration failed.
Type set repeat
Transfer of sensor types failed.
Monitor enabled
Sensor monitor enabled.
Monitor dis/man
Sensor monitor manually disabled.
Monitor dis/sen
Sensor monitor disabled by sensor.
Sensor module status information
SIStat
01-------12---0----0
Statuses of activated sensors (1 .. 20), "-" -> not used
SIIndx
11-------22---5----7
Sensor type as stated in 3.1.6.9.7. 1 = Dome cover, 7
= Handbrake.
Sensor events
SI
121208-130622 M:ON I: 1(1-2)
S:1(akt)
Online event.
Date(DDMMYY)-time (HHMMSS),
I: Sensor index input (sensor group - sensor group
index)
In this example: SI input 1 (DOM lid cover sensor no.
2)
S: Status (0/1) + interpretation whether acting as
closed or open (active/passive). Also 2 (interruption)
and 3 (short circuit) for Namur sensors.
In this example: ACTIVE
