MultiFlow  Printing out Reports
Event
Data
Meaning
121208-090536 M:OFF I:19(2-
1) S:1(akt)
Offline event read from sensor module logbook.
Date(DDMMYY)-time (HHMMSS),
I: Sensor index input (sensor group - sensor group
index)
In this example: SI input 19 (API coupling no. 1)
S: Status (0/1) + interpretation whether acting as
closed or open (active/passive). Also 2 (interruption)
and 3 (short circuit) for Namur sensors.
In this example: ACTIVE
Sensor module alarms:
Error
SI no Resp.
SI Intf.NoRsp
SI NamurNoRsp
SI NamResNoRsp
SI SetDatNoRsp
SI ScanIvNoRsp
SI FIFO NoRsp
SI SenTypNoRsp
SI SensorNORsp
Sensor module does not answer.
Message informs about the internal status of the
MFSI control.
SI Interf.: x
SI Onl.Err: x
Module error detected.
01: CAN error
02: SW Watchdog
04: HW Watchdog
08: RAM error
10: ROM error
20: Reset State
SI Namur: x
Defective SI Namur Status.
01: Low Battery
02: Logbook erased
04: Automatic wakeup disabled
08: Power-off
SI FIFO:x
Defective FIFO status.
01: Buffer overrun
02: FIFO recovered due to problem
04: FIFO cleared due to problem
SI type set
Sensor type could not be set.
System Alarms:
ALARM
Log corrupt
The logbook contains one or more invalid entries.
Log cleaned
The logbook entries have been completely deleted.
Password failed
An incorrect password has been entered.
SoftSeal failed
The seal has been broken because of an internal
error.
Low memory
Insufficient working memory is available to the
system.
EEProm failed
An error has occurred in the EEPROM memory.
CAN-Telegram
An unrecognized CAN telegram has been received.
Master Alarms:
ALARM
RAM Read/Write Test
Self test: RAM defective.
EPROM Checksum
Self test: EEPROM checksum defective.
Appl. Memory Test
Self test: Working memory defective.
