MultiFlow  Software update
15.2.2 Required hardware
Connect PC adapter (F. A. Sening Part No. MFLOW-PCADAP) to the
printer cable of the Sening system instead of the printer. In addition you
need a serial cable with adequate length provided with the following
allocations:
9 point SUB-D female plug
to connect to the serial port
of the laptop (normally COM1)
25 point SUB-D male plug
to connect to the PC adapter
Pin 5
Pin 7
Pin 2
Pin 3
Pin 3
Pin 2
Any standard modem cable (1:1 connection, not a cross-over cable!) is
equipped with this kind of allocation.
15.2.3 Procedure
 Check if the system is functioning correctly.
 Print out a list of all parameters.
 Save parameter setting to the chip card (parameter 4.5.2.).
 Switch off all devices involved (e.g. laptop, NOMIX, SPD, MultiFlow,
MultiSeal, EMIS).
 Disconnect RS232 printer cable from the printer and connect same to the
PC adapter at the side marked „MultiFlow“.
 Connect the earth wire of the PC adapter.
(Connect the black terminal of the PC adapter with the ground cable)
 Connect the laptop and the PC adapter with the modem cable (as
described in chapter 15.2.2.
Place the laptop outside any area with explosion hazards.
Do not operate the laptop with mains voltage, but equipped with
batteries (for laptop power supply voltage <24V) or on board
voltage only.
