MultiFlow  Initial Operation
5.7.2 Printer
The diagnostic functions for the printer are shown in Menu 4.3.2.
Menu 4.3.2
Selected printer →
Settings →
Check Text →
Echo →
Status →
System messages →
 
The display shown above gives a quick summary of the printer settings
currently selected:
• Selected printer (in the header)
• Type of interface (RS-232 or RS-485)
• Transmission speed (baud rate)
• Parity monitoring (even, odd or none)
When printer faults occur, the MultiFlow offers the possibility of executing
a so-called "loop-back test". This test enables the printer connection to be
tested for lead breakage (see chapter 5.7.2.1 "Loop-Back Test" / page
61).
5.7.2.1 Loop-Back Test
A so-called "loop-back test" is available to check the wiring. This test can
be executed with any printer linked.
 Remove the data cable from the printer and bridge the communications
lines.
Pri nt er ( 29 5)
Po rt : RS 232
Ba ud R at e : 96 00
Pa ri ty : No ne
Se nd
F .A . Se ni ng
R ec ei ve
F. A. S en in g OK!
R ea dy
Se lf te st OK
S ea l OK
Ve rs io n3 .0 4[ 3. 10] GB
--- -- - - --
