The remote control diagnostics screen firstly shows the following image:
Menu 4.3.4, ready
Status of the overfill prevention →
Status of the dead man’s switch →
Last incoming telegrams →
Of the various types .
Pre-set amount for test of →
The remote control .
The details in brackets concerning the functions “Level probe” and “Dead
man’s switch” have the following meaning (see parameter 3.1.6.n and
3.1.8.8):
„YES“ The function is activated. If the function is not being used the
entry reads “No“.
„N:0“ Defines the node number (address) of the base station that is
providing the function in question
„1.8s“ Defines the interval at which the base station must cyclically
provide a status value (heartbeat), or else the MultiFlow changes
to an error status.
The functions “Level Probe”, “Dead man’s switch”, and the remote
operation of the MultiFlow can be implemented via various base
stations. As a rule, however, only one base station is used, and this has
the node number “0”.
5.7.4.1
Check function
The “Idle” comment in brackets indicates that the readiness mode of the
MultiFlow has just been activated. To check the functions of the remote
control, a connection must first be made with one or several base
stations. This is achieved by pressing <F1>.
After the connection to the base station has been established, the display
in the handheld remote control is changed, as well as the status display
of the overfill prevention and the dead man switch.
