Menu 4.3.4, connected
Status of the overfill prevention →
Status of the dead man’s switch →
Last incoming telegrams →
Of the various types →
Preset amount for test of →
the remote control
In the first instance a small rectangle will jump repeatedly from left to
right. This symbolizes the “heartbeat” of the sensor. The changeover
takes place approximately twice per second. However, should the interval
become larger than the set maximum value, a connection fault may have
occurred and a “T” (for time out) appears behind the rectangle. In addition
the sensor status changes from “+” (for OK) to “-“ (for fault).
When the connection has been activated the MultiFlow simulates the
“preset” operating state. This enables the setting of a preset value via the
remote control (see also chapter 6.7 "Discharge operated remotely" /
page 84 and the MultiControl user manual). The alteration of the preset
value is displayed in the lower third of the display.
By pressing the key <F2> the MultiFlow changes to the “discharge”
operating state. This can similarly be checked on the remote operation
display.
