The diagnostic function can be used only when the connection to the IO
interface is active.
On exiting the diagnostic screen, the IO interface is re-initialized
according to the specified configuration.
It is essential that the functions of each output are noted.
5.7.7
Sensor interface
The diagnostic function for the sensor interface is contained in menu
4.3.8. For every sensor input used, the corresponding sensor status is
displayed. The statuses of the sensor inputs not used in the configuration
are indicated with '-'.
This menu item can be actuated only when the connection to the sensor
interface is active.
Diagnosis Menu 4.3.8
Status of the →
used sensor inputs
Possible statuses:
0 - open, 1- closed, 2 - interrupted, 3 - = short-circuited
Press the <F1> key to initiate an update of the overall status display.
Under normal circumstances this is not necessary however because all
statuses are updated automatically as soon as they have been detected
by the MultiFlow. There is a short delay between the change in status and
the display updating due to the internal evaluation logic.
