Terason t3000 - Measuring in the Spectral Doppler Modes

Chapter 7 - Working With Measurements Measuring in the Spectral Doppler Modes
Terason t3000 / Echo Ultrasound System User Guide 166
M-Mode Measurement
5. Print and save the image, if needed.
Measuring in the Spectral Doppler Modes
When you freeze a Pulsed-Wave Doppler, Continuous-Wave Doppler, or Triplex scan, the
Terason software adds the 2D Measure and PWD Measure (or CWD Measure) tabs to the
Image Control bar. The controls on the CWD Measure tab are identical to those on the
PWD Measure tab. The graphics in this section show the PWD Measure tab, and any
reference to the PWD Measure tab functions also applies to the CWD Measure tab.
PWD Measure Tab
