Working With Cardiac Reports
After making the appropriate measurements, you can generate a report. The report
includes several calculations based on the measurements. The following pages show the
format for the cardiac report. The x’s represent data either measured in the scan, or
calculated from those measurements.
Right
Ventricular
Systolic
Pressure from
Ventricular
Septal Defect
BP
sys
: systolic blood pressure
(mmHg)
V
max
:maximum velocity of
ventricular septal defect (m/s)
mmHg
Shunt Ratio CO
Qp
: pulmonic cardiac output
(l/min)
CO
Qs
: systemic cardiac output
(l/min)
—
Shunt
Difference
CO
Qp
: pulmonic cardiac output
(l/min)
CO
Qs
: systemic cardiac output
(l/min)
l/min
Example Echocardiography Report
Exam Type:
Report Date:
Patient Information
Patient:
Patient Id:
Sex: Height:
Birth Date: Weight:
BP: BSA:
Study Information
Study Date:
Accession Number:
Referring Physician:
Interpreting Physician:
Indications [Freeform text entered on worksheet]
Comments [Freeform text entered on worksheet]
2D & M-Mode Measurements
Ventricle Dimensions
Diastole Systole
RVAW: x.xx cm x.xx cm
RVID: x.xx cm x.xx cm
IVS: x.xx cm x.xx cm
LVID: x.xx cm x.xx cm xx % FT
LVPW: x.xx cm x.xx cm xx % FS
RVAW: x.xx cm x.xx cm xx % FT
Doppler Formulas (Continued)
Name Variables Formula Units
RVSP BP
sys
4V
2
max
–=
Qp
Qs
--------
CO
Qp
CO
Qs
----------------=
Qp Qs– CO
Qp
CO
Qs
–=
