Chapter 7 - Working With Measurements Measuring Vascular Exams
Terason t3000 / Echo Ultrasound System User Guide 180
Available Vascular Measurements
The following table lists the measurements available in each scan mode. Also see
Available Vessels Based on Exam on page 168.
Vascular and Cardiac Measurements by Window
Measurement Group Measurements Tool Used
Vascular Measurements in the 2D Image Display Window
Stenosis Diameter %Diameter Stenosis Caliper
Stenosis Area %Area Stenosis Trace
Vascular Measurements in the M-Mode Time Series Window
HR HR Time Caliper
Cardiac Measurements for PWD/CD Time Series Window
PS/ED PS Velocity Point
ED Velocity Point
RT RT Time Caliper
HR HR Time Caliper
Flow Volume FV Flow Volume
TAMV Derived
DIAM Derived
PI TAPV Pulsatility Index
PI_Vmax Derived
PI_Vmin Derived
