Chapter 1 - About the Terason Ultrasound System The Terason Console
Terason t3000 / Echo Ultrasound System User Guide 34
Image Control Bar/Measure Tabs
The Image Control bar shows tabs that let you configure settings to adjust the scanned
image and make measurements on frozen images.
Live Imaging Control Tabs
For live imaging, the Image Control bar shows the following tabs:
• 2D and I.Q. tabs for 2D imaging
• Additional tab for the selected scan mode
Frozen Image Control Tabs
When the image is frozen or when a ULT file is loaded, following the Image Control bar
tabs are available:
For a loaded file in a format other than ULT, this window shows an Info tab. See Storing
Images and Loops on page 131 for information about viewing saved files.
For information about how the image controls for the scan modes work, see Chapter 5,
Working With Scan Modes, on page 89.
For information about using the Measure tabs, see Chapter 7, Working With
Measurements.
The Terason Console
A slide-out console houses controls that configure and operate the Terason Ultrasound
system without using a mouse.
Tabs Displayed When Image Frozen or ULT File Loaded
Mode Tabs Available
2D
I.Q.
2D Measure
M-Mode
I.Q.
2D Measure
M Measure
CWD
I.Q.
2D Measure
CWD
CWD... (CWD Measure)
PWD
I.Q.
2D Measure
PWD
PWD... (PWD Measure)
CD
I.Q.
2D Measure
CD
Pwr
I.Q.
2D Measure
Pwr
