Appendix E - Electromagnetic Compatibility Tables Compatibility for Non-Life-Supporting Equipment
Terason t3000 / Echo Ultrasound System User Guide 331
Compatibility for Non-Life-Supporting Equipment
For transmitters rated at a maximum output power not listed above, the recommended
separation distance d in meters (m) can be estimated using the equation applicable to the
frequency of the transmitter, where P is the maximum output power rate of the transmitter
in watts (W) according to the transmitter manufacturer.
Guidance and Manufacturer’s Declaration—Electromagnetic Immunity—For Equipment and Systems That Are
Not Life Supporting (Table 204 from EN 60601-1-2:2001)
Immunity Test
IEC 60601 Test
Level
Compliance
Level Electromagnetic Environment - Guidance
Portable and mobile communications equipment should be
separated from the Terason Ultrasound System by no less
than the distances calculated/listed below
Conducted RF
IEC 61000-4-6
3 Vrms
150 KHz to 80 MHz
[V
1
] = 3 Vrms
Radiated RF
IEC 61000-4-3
3 V/m
80 MHz to 2.5 GHz
[E
1
]=3V/m
80 to 800 MHz
800 MHz to 2.5 GHz
where P is the max power in watts and d is the recommended
separation distance in meters.
Field strengths from fixed transmitters, as determined by an
electromagnetic site survey, should be less than the
compliance levels (V
1
and E
1
).
Interference may occur in the vicinity of equipment containing a
transmitter.
Recommended Separation Distances Between Portable and Mobile RF Communications
Equipment and the Terason Ultrasound System and Systems that Are Not Life-Supporting
Rated Maximum Output
Power of Transmitter
Watts (W)
Separation Distance According to Frequency of Transmitter
Meters (m)
IEC 61000-4-6 IEC 61000-4-3
150 kHz to 80 MHz 80 MHz to 800 MHz 800 MHz to 2.5 GHz
0.01 0.12 m 0.17 m 0.24 m
0.1 0.53 m 0.53 m 0.74 m
1 1.17 m 1.67 m 2.34 m
10 5.28 m 5.28 m 7.38 m
100 16.70 m 16.70 m 23.34 m
