Chapter 1 - About the Terason Ultrasound System Support for Medical Procedures
Terason t3000 / Echo Ultrasound System User Guide 29
Triplex applications include vascular studies, phlebology, perinatal, and radiology. The
following triplex image example shows the greater saphenous vein.
Example Triplex Scan
For more information on using Triplex mode, see:
• Acquiring Images on page 63
• Scanning in Triplex Mode on page 126
•
TeraVision
TeraVision is an optional image-optimization package that sharpens images produced by
the Terason Ultrasound system.
See Enhancing the Image Using TeraVision™ Optimization on page 76
Support for Medical Procedures
The Terason Ultrasound System can be configured with needle guides used for tissue
biopsy, fluid aspriation, amniocentesis, and catheter placement. The system can also be
incorporated into cryoablation (or targeted ablation) and brachytherapy products from
other vendors. The Terason Ultrasound System scans the anatomy or vessel for size,
location, and patency, and provides guide lines between which the needle will appear.
For biopsy and vascular puncture applications, a needle guide kit directs needles to the
proper location for percutaneous vascular punctures and nerve blocks. The needle guide
allows you to direct the needle into the center of a vessel or tissue mass, helping to avoid
adjacent vital tissue. You can see the anatomy in real time before, during, and after the
procedure, and can save images and Cine loops for future reference.
