Appendix E - Electromagnetic Compatibility Tables Compatibility for All Equipment
Terason t3000 / Echo Ultrasound System User Guide 330
Guidance and Manufacturer’s Declaration—Electromagnetic Immunity—For All Equipment
and Systems (Table 202 from EN 60601-1-2:2001)
Immunity Test IEC 60601 Test Level Compliance Level
Electromagnetic Environment -
Guidance
ESD
IEC 61000-4-2
+
6kV Contact
+
8kV Air
+
6kV Contact
+
8kV Air
Floors should be wood, concrete or
ceramic tile. If floors are synthetic, the
relative humidity should be at least 30%
EFT
IEC 61000-4-4
+
2kV Mains
+
1kV I/Os
+
2kV Mains
+
1kV I/Os
Mains power quality should be that of a
typical commercial or hospital
environment.
Surge
IEC 61000-4-5
+
1kV Differential
+
2kV Common
+
1kV Differential
+
2kV Common
Voltage Dips/
Dropout
IEC 61000-4-11
>95% Dip for 0.5 Cycle
60% Dip for 5 Cycles
30% Dip for 25 Cycles
> 95% Dip for 5 Seconds
>95% Dip for 0.5 Cycle
60% Dip for 5 Cycles
30% Dip for 25 Cycles
> 95% Dip for 5 Seconds
Mains power quality should be that of a
typical commercial or hospital
environment. The unit continues to operate
during a 5-second loss of power. However,
if the user of the Terason Ultrasound
System requires continued operation
during a longer power outage, Using an
uninterruptible power supply to power the
Terason system is recommended.
Power Frequency
50/60 Hz
Magnetic Field
IEC 61000-4-8
3A/m 3A/m Power Frequency magnetic fields should
be that of a typical commercial or hospital
environment.
