Chapter 7 - Working With Measurements Measuring Cardiac Exams
Terason t3000 / Echo Ultrasound System User Guide 199
Cardiac Output: x.xx l/min Cardiac Index: x.xx l/min/m
2
Velocity Gradient TVI Time
LVOT Mean: x.xx m/s x.x mmHg x.xx m xxx ms
PA Mean: x.xx m/s x.x mmHg x.xx m xxx ms
MV Mean: x.xx m/s x.x mmHg x.xx m xxx ms
LVOT Diameter: x.xx cm LVOT CSA: x.xx cm
2
PA Diameter: x.xx cm PA CSA: x.xx cm
2
MV Area (LVOT): x.xx cm
2
MV Area (PA): x.xx cm
2
Pulmonic Valve
Velocity Gradient TVI Time
PV Mean: x.xx m/s x.x mmHg x.xx m xxx ms
PV Peak: x.xx m/s x.x mmHg
PI Peak: x.xx m/s x.x mmHg
PV Diameter: x.xx cm PV CSA: x.xx cm
2
Stroke Volume: x.x ml
HR: xx bpm
Cardiac Output: x.xx l/min Cardiac Index: x.xx l/min/m
2
Tricuspid Valve
Velocity Gradient TVI Time
TV Mean: x.xx m/s x.x mmHg x.xx m xxx ms
TV Peak E: x.xx m/s x.x mmHg
TV Peak A: x.xx m/s x.x mmHg
E/A Ratio:
TR Peak: x.xx m/s x.x mmHg
PHT: xxx ms
TV Diameter: x.xx cm TV CSA: x.xx cm
2
Stroke Volume: x.x ml
HR: xx bpm
Cardiac Output: x.xx l/min Cardiac Index: x.xx l/min/m
2
RVSP
TR Peak: x.xx m/s x.x mmHg
RA Pressure: xx.x mmHg
RVSP (TR): xx.x mmHg
VSD Peak: x.xx m/s x.x mmHg
Sys BP: xx.x mmHg
RVSP (VSD): xx.x mmHg
Shunts
ASD Qp ASD Qs
TVI: x.xx m x.xx m
Example Echocardiography Report (Continued)
