3.4 Operation Procedure (Host Analyzer)
45
2. Setting up # Inq. Response: You can set the Inquiry to end after the “# Inq.
Responses” (1 to 16). If there are several DUT that have to respond to Inquiry, set the
number of Inquiry response to more than 1. But if there is only one DUT, set the
number of Inquiry response to 1 for testing speed. TC-3000C will stop discovering
when receives this number of inquiry responses or the Inquiry Timeout is expired.
Press F8 one times for “More 2/5” menu  Press F4
3. Setting up the profile type of DUT: You should define the profile type of DUT, before
beginning tests. To select the profile type, press F8 three times for “More 5/5”
menu in the Host Analyzer screen. press F2 and select the profile type of DUT.
4. Search for DUT: Press F8 for “More 1/5” menu  press F2 key to search for
all Bluetooth devices that are in range and in Inquiry Scan Mode through the Inquiry
procedure. If the DUT is connected to the TC-3000C through the USB(HCI) port, the
TC-3000C read the Bluetooth device (BD) address and controls the DUT directly
through HCI. If you want to stop Inquiry process, press
F2 key again.
5. Select a DUT: Select a DUT that you want to test in the found devices by using
Rotary Knob or 
 keys.
6. Connect/Disconnect: Create connection to highlighted DUT on the screen through
the Page procedure by pressing F3 . When the highlighted DUT is connected, this
menu changes to “Disconnect”. To make a SCO connection, press F4 .
[ Inquiry Parameters ]
Parameters
Range
Default
Descriptions
Inq. TO (1.28s)
1 ~ 48
48
Refer to Tester in Configuration
Page TO (slts)
1 ~ 65535
16000
Refer to Tester in Configuration
# responses
0 ~ 16
1
Refer to Tester in Configuration
HCI TO (ms)
1 ~ 65535
2000
Refer to Tester in Configuration
[ Scan Parameters ]
Parameters
Range
Default
Descriptions
Access Type
Discoverable
Connectable
Full Access
Full Access
Accessibility to Tester as a slave
T inqscan (slts)
18 ~ 4096
2048
Refer to Tester in Configuration
T winqscan (slts)
18 ~ 4096
18
Refer to Tester in Configuration
T pagescan (slts)
18 ~ 4096
2048
Refer to Tester in Configuration
T wpagescan (slts)
18 ~ 4096
18
Refer to Tester in Configuration
Scan TO (ms)
10000 ~
600000
Inquiry/Page Scan Timeout of Tester
NOTE
If you want to edit test configuration in detail, you can access to configuration
menus by pressing F8 in sequence. These menus operate globally;
changing the settings in this screen automatically changes that setting in all
screens where it is available. Refer to “3.9 Configuration.
