3.7 Operation Procedure (Audio Analyzer)
66
Parameters
Range
Default
Tone Freq (Hz)
1000, 400
1000
Tone level (dBm0)
-70 ~ 3
-10
CH1 Freq(Hz)
20~20000
1000
CH2 Freq(Hz)
20~20000
400
CH1 level(dBm0)
-70~3
-3
CH2 level(dBm0)
-70~3
-3
DUT RX level
-80 ~ 0
-30.00
Channel(3)
0-39-78
Meas.Mode
Continuous, Single
Continuous
Audio In (Hz)
1000, 400
1000
Audio Inport
Port1(BB IN1), Port2(BB IN2)
Port1(BB IN1)
Num of Avg
1 ~ 100
1
Lower Freq(Hz)
20~4000
200
Upper Freq(Hz)
20~4000
3500
