3.10 Configuration of the TC-3000C
76
SDP TO (ms)
1 ~ 65535
30000
SDP Timeout
Defines the timeout of SDP commands execution
Profile TO (ms)
1 ~ 65535
30000
Profile Timeout
Defines the timeout of Profile commands execution
Skip Pairing
Unchecked
This option will cause the TC-3000C to skip the pairing
process with DUT. To skip pairing, Link Key should be
entered.
Link Key
Specifies Link Keys
AFH
Enable
Disable
Disable
Defines AFH (Adapted Frequency Hopping) enabled.
Enabling this option causes the “Select Channel” menu to
display below.
Select Channel
Selects the AFH channels
Encryption
Enable
Disable
Enable
Defines Encryption enabled in the Tester’s LMP features.
Name Discovery
Checked
Defines whether to read DUT’s name after inquiry
procedure. (When the DUT use Broadcom chip, it is highly
recommended that this parameter is unchecked.
CSR HS1.2
Unchecked
To test CSR Head Set 1.2, check this option. Enabling this
option causes the TC-3000C to skip encryption before
activating test mode.
Friendly Name
Friendly Name is used for easy understandable name (ex
“TC-3000C”) of the device instead of Bluetooth device
address (ex “9ABC56781234”). It could be edited any
name.
Initiate
Authentication
Unchecked
In case of Checked, the Tester will request Authentication
procedure from the DUT.
Delay for TC
1 ~ 65535
ms
Time delay between Test mode setting using LMP
message and real measurement in Test case
Pause test
Unchecked
When you send a message about the control to the DUT
in the TC-3000C, you can set whether or not to use the
‘PAUSE’ between the message and the message. In case
of Checked, Pause between the message and the
message.
BCM20780
Unchecked
Check if you want to test ‘BCM 20780’ chip of ‘Broadcom’
