Chapter 3 ’Web Browser Interface’ — Basic Settings
76 Amethyst III DTV Smart Switch
User Manual
2.
Select the tests group to apply from the Associated group of tests
drop-down list. By default, there is only one group of tests, named
Tests group, and it is applied to all inputs. If you want to apply different
tests to the inputs, you need to define several groups of tests
beforehand (refer to
Section ’Editing a Tests Group’
on page 87).
Parameters specific to IP inputs
3.
Select the Ethernet port which supplies the stream in the Interface
field.
4.
Define the following IP parameters:
Source IP address if you have checked the Define source IP
address box
Source IP port if you have checked the Define source IP port box
Destination IP address (mandatory)
Destination IP port if you have checked the Destination IP
address box
IGMP protocol version (no IGMP, IGMP v2, IGMP v3, IGMP v3
with source address)
VLAN Id if you wish to define it
5.
If needed, activate the FEC correction of the IP input stream. The FEC
matrix type and size will be detected automatically.
Parameters specific to T2-MI option
6.
For a T2-MI stream, check the T2-MI Stream box and set the PID of the
stream in the field.
In all cases
7.
Enable the new settings by clicking the cross in the top right
corner of the dialog box.
For more information on items parameters, refer to the
Section ’ASI
Input Items’
on page 123 and
Section ’IP Input Item’
on page 124.
Proceed the same way for all inputs of your configuration.
