Chapter 3 ’Web Browser Interface’ — Basic Settings
82 Amethyst III DTV Smart Switch
User Manual
For more information on item parameters, refer to the
Section ’ASI
Output Item’
on page 130.
Parameters specific to TS over IP outputs
4.
Select the Ethernet port where the stream will be sent in the Interface
field.
5.
Check the Masquerading box (if required) then fill in the following
fields: Define source IP address, Define source UDP port, Define
destination IP address, Define destination UDP port.
Indicate if you want to use the same VLAN set
ting as in input (
Same
as input
), or if you want to force a VLAN setting (
Define VLAN
) in
which case you must indicate its identifier.
It is not possible to add a VLAN information if the original session
does not already contain VLAN.
6.
Check the FEC generation box if you want to generate FEC in output.
If so, choose the type of FEC that should be generated (
1D
or
2D
) and
indicate the number of rows and of columns of the matrix. FEC
generation is possible only over a CBR input stream over RTP.
7.
Check the Fail over box (if required) then select the backup Ethernet
port from the Backup interface drop-down list. It must be different
from the main one.
For more information on item parameters, refer to the
Section ’IP
Output Item’
on page 132.
Proceed the same way for all outputs of your configuration.
