OPUS Projektor Manual
Device Software Update
Other popular Error Codes are:
· (- 1) UD_FAILURE: It seems an unexpected error occurs. Just try again, and/or
restart the HostUpdater and ClientUpdater (device reboot).
· (-22) DEVICE MODEL MISSMATCH: It seems the device model name of the
project does not match with the device model name of the device connect on the
CAN bus.
· (-27) ACTIVE CAN INTERFACE: ClientUpdater has been already connected
via CAN. If the connection is broken during transfer, please wait a few seconds
before you try again to transfer the project.
· (-42) OPEN PORT FAILED: The HostUpdater can not open the CAN Interface.
(E.g. PEAK CAN Dongle is not plugged-in)
· (-408) BUS ERROR: It seems the CAN network is used with diffrent baud
rates.
Ethernet Update
If the Ethernet button is clicked on the Start Page, the Ethernet
Settings Page is shown. Here you can modify the Ethernet settings for the project
transfer.
Afterwards you can start the transfer.
Disclaimer about using Ethernet
The Ethernet Update mode is a little more complex than the USB Update mode.
Many things have to be considered. Otherwise the transfer won't work.
1. To transfer the project between HostUpdater and ClientUpdater, 2 Ports will
be used and must be configured properly.
2. The ClientUpdater only enables the Ethernet Interface if the value of the pre-
defined variable @EnableUpdater has been set to a value between 0x4
and 0x7. So check if the variable is set properly in the project (e.g. in a script
for the event OnProjektInit).
3. The first project update has to be done via the USB drive . With this update
the new Ethernet Settings for the device will be set.
Please follow these steps carefully.
PC Ethernet Settings Page
These settings will be used for the current project transfer. The settings shown here
have to be same as for the connected device, otherwise the transfer will not work.
Scan Network (Broadcast):
