Selecting Finishing Modes 121
5
Press the [MAGAZINE SORT] (or [MAGAZINE SORT & SADDLE
STITCH] or [SADDLE STITCH]) button.
y The [MAGAZINE SORT & SADDLE STITCH] button and the [SADDLE STITCH] but-
ton are selectable only when the Saddle Stitch Finisher is installed.
y Set other copy modes as required.
6
Press the [START] button.
When placing the originals on the original glass, follow the procedure in P.66 “Placing
originals on the glass”.
Available conditions for saddle stitching
Available paper sizes are LD, LT-R and LG.
*1 When the cover is added, the tray loading capacity is always 5 sets.
y One cover of 17 lb. Bond to 140 lb. Index can be added. In this case, this cover is included in
the maximum number of sheets that can have saddle stitching.
y When paper of a different weight is loaded, count the number of sheets for saddle stitching
as applied to the paper with the highest weight.
Paper weight
Saddle stitch tray loading capacity
11 - 15 sheets 6 - 10 sheets 5 sheets or less
17 lb. Bond 10 sets 20 sets 25 sets
20 lb. Bond 10 sets 20 sets 25 sets
24 lb. Bond
*1
- 15 sets 25 sets
28 lb. Bond
*1
- 15 sets 25 sets
To Next Page
