FM-750 Display User Guide 101
Mapping and Guidance 6
Mapping an A+ line
1. Drive to the start point of the master line.
2. Tap and then drive to the end of the line.
Because you have already set the line heading, the master AB line appears on the
screen.
3. For guidance down the first swath follow the AB line.
4. Turn left or right for the next swath. As you move toward the next swath, it
appears on the screen and turns orange to show that it is selected.
Identical curve
The identical curve pattern records your exact route
between the A and B points, instead of creating a straight
line. All subsequent guidance lines will match the master
curve, regardless of where you drive the vehicle.
Use the identical curve pattern when you want to work a
field with gentle curves.
Mapping an identical curve
1. Drive to the start point of the curve.
2. Tap and then drive the initial curve.
3. When the icon is highlighted, tap . The master curve appears on the screen.
4. Turn left or right for the next swath. As you move toward the next swath, it
appears on the screen and turns orange to show that it is selected.
Adaptive curve
The adaptive curve pattern provides guidance along a
curve and updates guidance after each swath to take into
account any deviations you make. It continually records
your path and provides guidance that matches the last
path you drove.
Mapping an adaptive curve
You can map an adaptive curve either manually or
automatically. The method you use depends on the Auto
U-turn detection setting.
To change the Auto U-turn detection setting:
1. In the Settings screen, tap
Guidance.
2. Tap
Turn Settings, then Auto U-Turn Detection.
