FM-750 Display User Guide 91
Mapping and Guidance 6
Turn Settings
The available Turn Settings are described below.
Minimum turn radius mode
This setting smoothes corners on curved AB lines, which optimizes the accuracy of
your auto steer system when steering curves.
Tight turn alert threshold
The FM-750 display alerts you when your machine is within a specified distance of a
tight turn.
The threshold is set between 1 and 10. To increase the sensitivity of the alert, lower the
number.
Auto U-turn detection
Auto U-turn detection operates only on FreeForm and adaptive curve patterns. For
more information, see Guidance Patterns, page 99.
Use this mode ... To ...
Automatic
(This is the default mode.)
Set the radius to 80% of the swath width or 32.8' (10 m),
whichever is larger.
Disabled No attempt is made to keep the corners above a minimum turn
radius.
Note – If you use this mode, curves may be very tight and the
auto steering system may be unable to successfully complete the
turn.
Manual Manually choose the minimum radius.
Use this mode ... To ...
On Automatically detect that the vehicle has done a U-turn and
generate the next guidance line.
Off Manually control when a path is finished. With the FreeForm
pattern you must manually stop recording. With the adaptive
curve pattern you must manually set the B point.
