FM-750 Display User Guide 93
Mapping and Guidance 6
Warning distance
You can set a warning distance so that the FM-750 display alerts you when your
machine approaches a feature.
As the machine moves to within the specified distance, a warning screen appears on
the display. If you have an EZ-Steer or Autopilot system with a sonalert connected, an
audible alarm also sounds.
You can set the warning distance to between 0'00" - 984' 03" (0.0 - 300.0 m).
Recording position
Choose the point at which a feature is recorded. When your vehicle is at this point, the
feature will be recorded.
Delete features
Use this function to delete point, line and area features from a selected field. Note that
this function deletes only the features, not the field itself.
FreeForm Recording
Use this setting to choose how the display records a FreeForm pattern:
Headland/Infill Switching
Use this setting to choose how guidance switches between the headland and the infill
part of the field:
Choose this mode ... If you want to ...
Manual Use the icons on the guidance screen to control when the path is
recorded.
To start recording tap , to stop, tap .
Record with coverage Automatically begin and end recording the FreeFrom pattern when
coverage logging begins and ends.
Note – You can still use the FreeForm recording icon to manually
override recording.
Select this mode ... To ...
Automatic Automatically switch from headland to infill when the vehicle
moves inside the inner headland boundary.
Manual Use the icons on the guidance screen to select when guidance
switches from headland to infill.
