6 Mapping and Guidance
96 FM-750 Display User Guide
Using guidance on curved segments
After you have defined a guidance line, there are two ways to get guidance:
• Drive the vehicle through a tight U-turn. The next guidance line appears.
• If you are manually logging a FreeForm curve, tap to stop defining the
current line.
The FreeForm curve is similar to an adaptive curve. You must record your line on each
pass to receive guidance on the next. If the vehicle is not drawing a line (or guidance
trail) behind it, you are not recording your path and therefore the next guidance line
will not appear.
Note – Do not confuse the existing guidance line with the guidance trail appearing behind
the vehicle that shows your current guidance. You need to create a new guidance line to
receive guidance on the next pass.
Using guidance on straight segments
When driving on straight AB lines, you do not have to record your path because the
guidance lines are generated automatically.
Creating straight sections on Headland or Curve swaths
To create straight sections when recording headland or curve swaths:
1. Tap .
2. Drive the section.
3. Tap to finish recording the straight section and to start recording a
curve again.
Fields
A “field” is specific area of land where events (such as planting seed or applying
fertilizer) are carried out.
You create your first field when you first configure your implement (see Starting
Guidance, page 94). That field remains open until you do one of the following:
• Create a new field, or load a previously saved field
• Calibrate your EZ-Steer system
• Perform a hard reset
Note – Fields are stored automatically. You do not have to actively save a field.
The following sections describe how to use the field function when there is already a
field currently loaded on the display.
