9 System
124 FM-750 Display User Guide
Backlight
You can adjust the brightness of the screen backlight to maximize visibility and reduce
glare in different light conditions. For more information, see Color Scheme, page 123.
Touchscreen speaker volume
You can adjust the volume of the speaker according to your preference. Choose from
Loud, Quiet or Off.
Lightbar Setup
You can adjust the lightbar settings as follows:
Use this setting ... To ...
Look Ahead Allow time for large vehicles to correct offline error:
• For large vehicles that take longer to turn, increase the look
ahead time.
• For 4WD articulated tractors, always set the look ahead time to
0 seconds.
Look ahead time applies to LED guidance only and does not affect
EZ-Steer performance.
Set the look ahead time in seconds.
LED Spacing
Note – The LED spacing
is the distance
represented by one LED.
Adjust the sensitivity of the LEDs. To:
increase sensitivity, decrease the LED spacing
decrease sensitivity, increase the LED spacing
LED Brightness Adjust the LED brightness for maximum visibility.
Main Lightbar LED Mode Select the required LED mode. There are two modes to choose
from:
• Chase: Chase the lights to stay online. The lights represent the
swath location relative to the vehicle.
• Pull: Center the lights to stay online. The lights represent the
vehicle location relative to the swath.
