FM-750 Display User Guide 95
Mapping and Guidance 6
3. Edit the settings for each option. For more information, see Implement Setup
options, page 95.
4. Select a pattern type (see Guidance Patterns, page 99) and continue through the
wizard.
Implement Setup options
For optimum guidance, make sure that you enter accurate information for the
implement that is attached to the vehicle. Incorrect information may result in gaps and
overlaps in coverage.
The following table describes each of the Implement Setup options:
Option Enter a
measurement
between ...
This adjusts guidance
and coverage
logging when ...
Notes
Implement Width 1' 00" - 328' 01"
(0.305 - 99.990 m)
Overlap/Skip 394" skip and 394"
overlap
(1000 cm).
• To avoid skips in application
coverage, set an intentional overlap.
Left/Right Offset 1969" right and 1969"
left
(5000 cm).
The implement if offset
from the vehicle center
line.
• When configured and online, the
implement should be over the
guidance line, with the vehicle to
the side.
• For guidance when driving, use the
LEDs on the lightbar. For more
information, see Reading lightbar
patterns, page 39.
Forward/Back
Offset
1188" behind and 384"
forward
(3018 cm - 975 cm)
The implement is not
centered directly under
the GPS antenna (for
EZ-Steer systems) or the
fixed axle of the vehicle
(for Autopilot systems).
• Set a Forward Offset when the
implement is forward of the antenna
(on the front of the vehicle) for EZ-
Steer systems, or forward of the
fixed axle of the vehicle for
Autopilot systems.
• Set a Back Offset when the
implement is behind the antenna
(on the back of the vehicle) for EZ-
Steer systems, or behind the fixed
axle of the vehicle for Autopilot
systems.
Implement Draft 393.7" left and 393.7"
right
(1000.0 cm).
There is a variable
implement draft caused
by a side slope and/or
an implement pulling
to one side.
Implement Mount
Type
Choose the type of implement mount
that is in use
