5 Implement Application Controller
84 FM-750 Display User Guide
Turn Off Rate on Overlap
Use this option to view and adjust the following settings:
Operation
When you connect the Amazone controller to the display, the following items appear
on the display’s guidance screen:
Settings ... Notes ...
Yes Does not spray over an area that has been previously sprayed.
No Sprays over an area that has been previously sprayed.
Item Notes
Actual rate
Target rate If a prescription is loaded, P displays to indicate that the prescription
rate is being used rather than the target rate.
Boom section status
indicators
Shows the current state of each boom section:
• Green: Enabled and spraying
• Gray: Enabled but not currently spraying
• Red: The section is off (the switch is off)
Application indicator The wheel spins when the Amazone master switch is on and the
lightbar receives flow messages from the controller.
Quick Access icon See, Quick Access icon, page 35.
