6 Mapping and Guidance
94 FM-750 Display User Guide
Boundary setup
Use the Boundary Setup option to configure:
• when boundaries are active. See Boundaries, below.
• how the display records boundaries. See Expand Boundaries, below.
Note the following:
• When you record a boundary, the display automatically calculates the area of
the boundary and displays this information on the Status tab.
• When you load a field that contains a boundary, the boundary also loads.
• You can record multiple boundaries in a single field.
• If your variable rate controller has section switching capability, a boundary acts
as a switching barrier. When you move outside the boundary, the controller will
automatically switch off the implement.
Boundaries
Expand Boundaries
Use this setting to determine how the display manages the boundary after you finish
recording.
Starting Guidance
Before you can use the display for guidance, you must configure your implement:
1. From the guidance screen, tap and then tap
Create New Field.
2. In the Create New Field screen, tap
Implement Setup.
Select this mode ... To ...
Enabled Use existing boundaries and create new ones for all your fields.
Disabled for this field Turn off boundaries for only the current field you are working in.
When you begin your next field, the option will automatically
change to Enabled.
Disabled for all fields Turn off boundaries for all fields you work in, including boundaries
made with headland patterns.
If you select this mode ... The boundary will ...
Do not expand Not alter once you have finished recording
Half swath width Expand by one half swath width toward the outside of the
pass
One swath width Expand by one full swath width toward the outside of the pass
