5 Implement Application Controller
76 FM-750 Display User Guide
Note – In the GPS group, if ‘Send time’, ‘Time acknowledge’ or ‘Close file’ appear, change
them to GPS Inac. Otherwise, the DLOG or DATA LOG option will not appear.
For more information on configuring and calibrating the Raven controller, refer to the
Raven instruction manual.
Advanced
Use the Advanced option in the Implement screen to configure the following:
• Boom Setup
• Target Rate
• Rate Snapping
Boom Setup
Use this option to view and adjust the following settings:
Target Rate
Set the target application rate that will be sent to the Raven controller. Enter a rate
between 0.0 - 11000.0.
Rate Snapping
Due to pump constraints, liquid flow is generally inconsistent. To control how these
inconsistencies appear on your display, turn rate snapping on or off.
Setting ... Notes ...
Implement width Enter a width between 1' 00" - 328' 01" (0.30 - 99.99 m).
Number of sections Enter a number between 1 - 10.
Setting ... Notes ...
On Matches the applied rate to the target rate when within 10% of the value.
Off Shows all fluctuations in the actual applied rate.
