FM-750 Display User Guide 59
Implement Application Controller 5
– Raven, page 75
– Rawson, page 78
– Amazone, page 82
– LH 5000, page 85
Prescriptions
The FM-750 display can use a prescription file to determine the rate of application in
different areas of the field.
The prescription file consists of three separate ESRI files: .shp, .dbf and .shx. Each of
these files contain different attribute information that the display uses.
You must load a prescription from the USB drive to the internal memory of the FM-750
display. The display cannot read prescriptions directly from a USB drive. For more
information, see the section below.
Loading a prescription
1. Copy the prescription file from your computer to the AgGPS/Prescriptions folder
on your USB drive.
Note – If you do not have an AgGPS directory on your USB, create one by exporting field
data to the USB. For more information, see Sending data to the USB drive, page 119.
2. Insert the USB drive into the USB socket, and then copy the prescription file to
the display’s internal memory. See Retrieving data from the USB drive, page 119.
3. From the guidance screen, tap to create a new field or select an existing
field.
The FM-750 display searches the internal memory for prescription files, and
after you define or select a field, the following screen appears in the wizard:
