The Satellite Status screen displays information about the current satellite
constellation.
The information for each satellite is contained in one line. The following table
describes fields that the line contains:
DGPS Status
The DGPS Status screen displays which DGPS signal is selected from the GPS
Correction Source screen. For more information, see GPS Setup, page 110.
Filter Status
The Filter Status screen provides diagnostic information about the OnPath
®
advanced
filter technology.
Field Description
Sv Satellite number
Note – GLONASS satellites have an "R" in front of the satellite number; GPS
satellites do not.
El Elevation
Az Azumith
L1 L1 SNR
L2 L2 SNR
Corr Correction (Only appears if correction is applied)
Used Used (Only appears if the satellite is used in position calculation)
