4 Vehicle
52 FM-750 Display User Guide
EZ-Steer calibration
In this step you must drive and engage on a straight AB line in a clear field:
1. Begin driving and tap .
2. Drive 160 feet and then tap .
A series of calibration screens will allow you to adjust any settings as necessary.
Operation
You must calibrate and set up the EZ-Steer system before operation.
Engaging the system
Before you can engage the EZ-Steer system, you must:
• open a field in the guidance screen
• define an AB line
• position the vehicle within the configured engage limits
To engage the system:
1. Point the nose of the vehicle toward the guidance line and drive at operational
speed.
2. Do one of the following:
– From the guidance screen, tap .
– Press the optional remote engage foot pedal.
Disengaging the system
The EZ-Steer system automatically disengages when one of the following happens:
• The vehicle is outside the configured engage limits.
• You pause the system.
• GPS positions are lost.
• You tap the Engage button on the guidance screen.
You can manually disengage the EZ-Steer system by turning the steering wheel (this
overrides the electric motor). Check this setting before you start using the system by
engaging on a line and then turning the wheel until the system disengages. To adjust
the amount of force required to disengage the system, change the Override Sensitivity
in the Engage Options screen.
