6 Mapping and Guidance
92 FM-750 Display User Guide
Coverage Settings
Configure the Coverage Settings options to suit the requirements of your system.
Coverage on/off delay
If you activate coverage logging at the same time as you enable your spraying or
spreading system, set a coverage delay that matches the time it takes for flow to start
when you turn on your spraying/spreading system. This ensures that the display
records coverage from the actual start point of application. You can enter a delay time
between 0.0 - 10.0 seconds.
Coverage logging
Nudge Settings
Mapping
Use this setting to set warning distance and recording positions for the following
features:
• Point
• Line
• Area
Use this mode ... To ...
Disabled Turn coverage logging off.
Manual Turn coverage logging on and off manually.
Engaged Automatically enable coverage logging when the auto steer
system is engaged.
Switch Use a remote switch to turn coverage logging on or off.
Option Description
Clear nudge at
swath end
When enabled, the display clears the nudged position each time you
change swaths.
Reset nudge When enabled, any applied nudge is cleared and all swaths return to their
original positions.
Nudge
increment
Each nudge moves the guidance line by this value. The default nudge
increment is 0' 1" (2.5 cm). Enter a value between 2 - 12" (3 - 30 cm).
