Trimble FM-750 - Advanced

FM-750 Display User Guide 79
Implement Application Controller 5
Advanced
Use the Advanced option in the Implement screen to configure the following:
• Boom Setup
• Swath Control
• Target Rate
• Default Rate
• Step Size
• Rate Snapping
Boom Setup
Use this option to view and adjust the following settings:
Swath Control
Use this option to view and adjust the following settings:
Target Rate
Set the target application rate that will be sent to the Rawson controller. Enter a rate
between 0.0 - 11000.0.
Alternatively, you can load a prescription so the FM-750 display will automatically send
target rates to the Rawson controller.
Note – When the FM-750 display is sending target rates to the Rawson controller, the
Rawson controller will only display the Target Rate screen. To change or view any other
screen on the Rawson controller, you must unplug the FM-750 display cable.
Setting ... Notes ...
Implement width Enter a width between 1' 00" - 328' 01" (0.30 - 99.99 m).
Number of sections Enter a number between 1 - 10.
Setting ... Notes ...
Boom control Enter a width between 1' 00" - 328' 01" (0.30 - 99.99 m).
Coverage switching overlap Control the amount of boom switching overlap allowed before the
section will be switched by the system.
Enter a value between 1 - 99%.
Boundary switching overlap Control the amount of overlap on a boundary before the boom section
is switched off.
Enter a value between 1 - 99%.
On/Off valve latency Tune the section switching to allow for hardware delays.
Enter a time between 0.0 - 10.0 seconds.
Intentional overlap Set a distance to be overlapped when moving to an unsprayed area or
out of a sprayed area.
Enter a distance between 0' 00" - 32' 10" (0.00 - 10.00 m).
