6 Mapping and Guidance
104 FM-750 Display User Guide
Reselecting the headland
When you use the headland pattern you can see either the headland or the internal
pattern.
To see the headland guidance again when you are driving the internal pattern, drive
into the headland before the first internal swath or after the final internal swath. The
headland appears automatically.
Mapping a headland
1. Drive to the start point of the headland.
2. Tap to set the start point of the headland.
3. Begin to drive the circuit of the headland.
Note – To ensure straight sides on the headland, you can use the pause feature. See
Creating straight sections on Headland or Curve swaths, page 96.
4. Tap to set the A point of your guidance line. If the internal pattern is an:
– A+ line, the line is set.
– an AB Line, continue to drive around the headland. When you reach the
other end of the internal guidance line, tap to set the B point.
When you have defined the internal pattern guidance line, the start-point circle
appears around the start point of the headland.
Note – If you return to the start of the headland before you define a guidance line, the
headland will not complete.
5. To complete the headland, do one of the following:
Note – Define the master line for the internal pattern before you complete the headland.
– Drive around the rest of the headland until you return to the start-point
circle. When you drive into the start-point circle, the headland completes
automatically.
– Drive part of the headland and then tap . The headland completes
with a straight line from the vehicle position back to the start point.
Once you have completed the headland, the headland guidance line appears.
When the vehicle moves out of the headland and into the interior of the pattern, the
interior is populated with your selected the guidance line pattern (straight AB or A+).
