4 Vehicle
56 FM-750 Display User Guide
To engage the system:
1. Point the nose of the vehicle toward the guidance line and drive at operational
speed.
2. Do one of the following:
– From the guidance screen, tap .
– Press the optional remote engage foot pedal.
Disengaging the system
The Autopilot automated steering system automatically disengages when one of the
following happens:
• The vehicle is outside the configured engage limits.
• You pause the system.
• GPS positions are lost.
• You tap the Engage button on the guidance screen.
You can manually disengage the system by turning the steering wheel (this overrides
the electric motor). Check this setting before you start using the system by engaging on
a line and then turning the wheel until the system disengages. To adjust the amount of
force required to disengage the system, change the Override Sensitivity in the Engage
Options screen.
Engage status indicators
After using the Autopilot automated steering system
• Any time that you are not using the system, pivot the Autopilot automated
steering system motor away from the steering wheel.
• Before you leave the vehicle turn off the system power switch or remove the
power plug.
Engage status Icon color
Ready to engage
Engaged
Cannot engage
