Trio Motion Coordinator MC216 - Page 155

5-29 Expansion Modules
Communications Adaptors
Trio Motion Technology
Motion Coordinator Side Pins:
RS485 Side Pins:
9 Way Male ‘D’ Connector:
1
+5v input to power adapter
2
RS232 Receive pass-through
3
RS232 Transmit pass-through
4
0v input to power adapter
5
RS232 Pass-through 0v
6
no connection
7
Transmit enable input
8
Logic level receive
9
Logic level transmit
25 Way Female ‘D’ Connector:
1..4 No connection
5 RS485 Gnd
6 RS485 A A REC
7 RS485 B B /REC
8 RS485 Z Z /TRAN
9 RS485 Y Y TRAN
10
11 RS232 Receive pass-through
12 RS232 Transmit pass-through
13 RS232 Pass-through 0v
14..25 No Connection
