1-8 Introduction
Products
Trio Motion Technology
*
(Available for use with MC206 and MC224 only)
Custom Daughter Boards
Trio can produce custom daughter boards for specific customer applications where
required.
P290 CAN Digital Link to CANBus drives
The combination of the motherboard CAN channel and
the ability to add up to 4 CAN daughter boards allows
the MC216 to potentially control up to 5 CAN channels.
P291* SERCOS Digital Link to SERCOS drives
The SERCOS daughter board provids digital control to
appropriate servo drives via a Fibre Optic loop. Up to 8
axes can be connected to each P291, which allows the
MC224 to control up to 24 axes.
P292 SLM (Drivelink) Digital Link to SLM drives
The SLM daughter board is aimed at providing digital
control channels for servo drives utilising the SLM proto-
col.
P295 USB Interface Universal Serial bus interface for high-speed PC
communications
The USB daughter board provides a very high speed
interface between the motion coordinator and a host
PC fitted with a USB port. Support for this high speed
interface is included in Trio's MotionPerfect 2 applica-
tion and software libraries are in development to allow
developers to support the interface within their own
programs.
P296* Ethernet Ethernet LAN Interface
The Ethernet daughter board enables the Motion Coor-
dinator to be connected to a local factory or office net-
work. Supports TCP/IP using the 10Base-T physical
layer.
P297 Profibus Profibus Fieldbus Interface
With the Profibus Daughter Board and appropriate soft-
ware on the Motion Coordinator, it is possible to con-
nect to external devices using the Profibus protocol.
Product
Code:
Name Description
