Installation Pipe System TITANUS MICRO·SENS
®
6 – 4 Data: 01/09 MS_A_06-en-e
There are two fixing points for the plastic pipe clip CLIC-PA when install-
ing the pipes:
1. Position 1 (first locking into place):
Fixes the pipe so that a linear expansion is possible (used in deep
freeze areas, if necessary).
2. Position 2 (second locking into place):
Fixes the pipe and avoids linear expansions.
Pipe Clips for ø 25 mm Type
standard pipe clips pipe clip
type NG 23 (ø 25 mm)
pipe clips for areas with high temperature
differences and deep freeze areas
plastic pipe clip
Type CLIC-PA (ø 25 – 28 mm)
pipe clips for deep-freeze areas and high
rack storage areas
spring steel clip type SNAP CLIP SC (for
profiles 1-4 mm)
spring steel clip, type SNAP CLIP SC (for
profiles 4-7 mm)
spring steel clip, type SNAP CLIP SC (for
profiles 8-12 mm)
