Commissioning TITANUS MICRO·SENS
®
7 – 8 Data: 01/09 MS_A_07-en-e
7.4 Testing the detection unit and
alarm forwarding
Trigger the TITANUS MICRO·SENS
®
and test the transmission route to
the FAS as follows:
1. Spray the test aerosol either into the first aspiration aperture or into
the TITANUS MICRO·SENS
®
pipe system test adapter.
2. Proceed on the basis of the following table.
Check whether ... If this is not the case ...
the alarm on the air sampling smoke de-
tection system is displayed.
1. check whether the display plate is
connected.
2. there is a fault in the air sampling
smoke detector.
3. change the detection unit.
the alarm is transmitted to the FAS and
notified on the associated line.
1. check the transmission routes.
If the LOGIC·SENS is set to “ON” in the “Settings” screen of the
diagnosis tool (see Chapter 5.3 "Settings"), then this must be set to
"OFF" for testing triggering the alarm with the test aerosol, in order to
speed up alarm assessment.
Note all test data in the test record.
INSTRUCTION
INSTRUCTION
