WAGNER TITANUS User Manual

Pipe Design TITANUS MICRO·SENS
®
4 – 18 Data: 01/09 MS_A_04-en-e
M-Pipe
TITANUS
M-pipe system
A
B
®
Fig. 4.5: M –Pipe system
Aspiration apertures
Number of apertures
3 6
Sampling aperture ∅
in mm
3F
4)
A 5.0 3.6
B
—
4.0
Double-U-Pipe
T
I
T
A
N
U
S
Double-U-pipe system
®
A
B
Fig. 4.6: Double -U –Pipe system
Aspiration apertures
Number of apertures
4 8
Sampling aperture ∅
in mm
4
)
A 4.4 3.0
B
—
3.8
4
Press cut diameter in aspiration-reducing film sheet

WAGNER TITANUS Specifications

General

Power Supply	24 V DC
Operating Temperature	-20°C to +60°C
Alarm Output	Relay contacts
Certification	VdS, EN 54
Humidity Range	10% to 95% (non-condensing)
