Technical features and description
Block diagram
TPS
Pulser coil
Neutral switch
Air pressure
sensor
Air temperature
sensor
Engine temperature
sensor
Main battery
Engine shut-off switch
Shift cut switch
Shift cut signal
Emergency stop
Battery voltage
Engine temperature
Intake air temperature
Intake air pressure
Neutral position
Throttle valve opening
Crankshaft angle,
Engine speed
Engine
ECM
Ignition signal
Ignition signal
Ignition coil #1 and #4
Ignition coil #2 and #3
