11.1 List of Parameters
11.1.2 List of Parameters
11-11
11
Parameter List
PnBA0
2
/MODE (Mode
Switch Input)
Signal Allocation
0000h to
00C3h
− 0000h
After
restart
Setup page 5-10
PnBA1
2
/START
(Program Table
Operation Start
Input)
Signal Allocation
0000h to
00C3h
− 0010h
After
restart
Setup page 5-10
Continued on next page.
Continued from previous page.
Parameter
No.
Size Name
Setting
Range
Setting
Unit
Default
Setting
When
Enabled
Classi-
fication
Reference
n.X Signal Usage Method
0 Use mode 0 (program table operation) when the input signal is ON (closed).
1 Use mode 0 (program table operation) when the input signal is OFF (open).
2
Always use mode 0 (program table operation).
Note: The signal allocation to the CN1 connector pin is disabled.
3
Always use mode 1 (jog speed table operation).
Note: The signal allocation to the CN1 connector pin is disabled.
n.X Signal Terminal Number
0 Input signal from CN1-3.
1 Input signal from CN1-4.
2 Input signal from CN1-5.
3 Input signal from CN1-6.
4 Input signal from CN1-8.
5 Input signal from CN1-9.
6 Input signal from CN1-10.
7 Input signal from CN1-11.
8 Input signal from CN1-12.
9 Input signal from CN1-13.
A Input signal from CN1-14.
B Input signal from CN1-15.
C Input signal from CN1-16.
n.X Reserved parameter (Do not change.)
n.X Reserved parameter (Do not change.)
n.X Signal Usage Method
0 Start program table operation when the /START signal turns ON (closes).
1 Start program table operation when the /START signal turns OFF (opens).
2, 3 Do not start program table operation.
n.X Signal Terminal Number
Same as PnBA0 = n.X.
n.X Reserved parameter (Do not change.)
n.X Reserved parameter (Do not change.)
