5.13 Setting User-Defined Functions
Procedure
1.
Press SETUP to display the Setup menu.
If the full Setup menu does not appear, proceed to step 2. If the full Setup menu appears,
proceed to step 4.
2.
Use the cursor keys to select Details.
3.
Press SET to display the full Setup menu.
4.
Use the cursor keys to select User Function.
5.
Press SET to display the User-Defined Function Settings dialog box.
Selecting Whether or Not to Compute a User-Defined Function
6.
Use the cursor keys to select the user-defined function that you want to set.
7.
Press SET to select ON or OFF. If you select ON, the ON/OFF indicator lights.
ON/OFF indicators
