5.17 Setting Delta Computation (Optional)
Procedure
Selecting the Target Wiring Unit for Delta Computation
For information about selecting a wiring unit, see section 4.2, “Selecting a Wiring
System.”
(Depending on the wiring system, this operation may not be necessary.)
Selecting a Delta Computation Type
1.
Press SETUP to display the Setup menu.
If the full Setup menu does not appear, proceed to step 2. If the full Setup menu appears,
proceed to step 4.
2.
Use the cursor keys to select Details.
3.
Press SET to display the full Setup menu.
4.
Use the cursor keys to select Delta Measure.
5.
Press SET to display the Delta Measure Settings dialog box.
6.
Use the cursor keys to select Meas Type.
(The menu varies depending on the wiring system.)
7.
Press SET to confirm the selection.
Selecting a Delta Computation Mode
8.
Use the cursor keys to select
Δ
F Mode.
9.
Press SET to set the delta computation mode to rms, mean, dc, r-mean, or ac.
