14.12 Ethernet Interface Option
Item Specifications
Ports 1
Connector RJ-45
Electrical and mechanical
specifications
IEEE802.3
Transmission system Ethernet (100BASE-TX)
Data rate 100 Mbps max.
Communication protocol TCP/IP
Supported services FTP server, DHCP, DNS, and remote control (VXI-11)
14.13 Safety Terminal Adapter
Item Specifications
Maximum allowable current 36 A
Withstand voltage 1000 V CATIII
Contact resistance
10 m
Ω
or less
Contact section Nickel plating on brass or bronze
Insulator Polyamide
Core wire Maximum diameter 1.8 mm
Insulation Maximum diameter 3.9 mm
