13-6
IM 760201-01E
13.3 Self-Test
Procedure
1.
Press MISC to display the Misc Menu.
2.
Use the cursor keys to select Selftest.
3.
Press SET to display the Selftest menu.
4.
Use the cursor keys to select Test Item.
5.
Press SET to display the Test Item menu.
6.
Use the cursor keys to select Memory or Key Board.
If you select Memory, proceed to “Performing a Memory Test.”
If you select Key Board, proceed to “Performing a Panel Key and Keyboard Test.”
Note
The time display in the lower right of the screen may freeze during the self-test.
Performing a Memory Test
7.
Use the cursor keys to select Test Exec.
8.
Press SET. The WT500 executes a memory test. The results appear after the test
finishes.
To Next Page
