YOKOGAWA WT500 User Manual

11-15
IM 760201-01E
Ethernet Interface (Optional)
3
2
1
4
5
6
7
8
9
10
11
12
13
14
App
Index
11.5 Checking the MAC Address and Whether the
WT500 Is Equipped with the Ethernet Interface
Option
Procedure
1.
Press MISC to display the Misc Menu.
2.
Use the cursor keys to select System Overview.
3.
Press SET to display the System Overview window.
The System Overview window shows the MAC address and whether or not the WT500 is
equipped with the Ethernet interface option.
Explanation
Ethernet Interface Option Availability
Whether or not the WT500 is equipped with the Ethernet interface option is indicated
next to “Ethernet Interface” in the System Overview window.
•
If “Yes” is displayed, the Ethernet interface option is installed.
• If “No” is displayed, Ethernet interface option is not installed.
MAC Address
The WT500 MAC address is a fixed preset address. It is indicated next to “Mac Address”
in the System Overview window.
Note
The MAC address only appears on models with the Ethernet interface option. If your
WT500 is equipped with the Ethernet interface option but the MAC address is displayed as
“xxxxxx_xxx_xx,” contact your nearest YOKOGAWA dealer.
